модель :
3010-02
The Armstrong Locks Cabinet Glass Door Hinge 3010-02 is a high-quality brass hinge designed for glass doors with thicknesses of 6mm or 8mm. Available in Chrome, Black, or Golden finishes, it supports up to 12 kg per pair, making it ideal for showcases, jewelry cabinets, and glass furnitur
High quality brass glass cabinet hinge
- 3010-02 For glass thickness 8mm
- 3010-02-6 For glass thickness 6mm
Made of brass: Chrome, Black or Golden finishes are available
- CABINET GLASS DOOR HINGE –LOADING WEIGHT:12KGS
Suitable for glass showcase and jewelry cabinet.
MOQ: 80prs/carton: G.W.:28KG
ITEM NO.:
＊3010-02 For glass thickness 8mm
＊3010-02-6 For glass thickness 6mm
Loading weight: 12kgs
| ORDER NO. | ORDER NO. | FINISH |
| C3010B-02 | C3010B-02-6 | CHROME |
| BK3010B-02 | BK3010B-02-6 | BLACK |
MATERIAL: Brass
UNIT: Pair
*Glass door must be drilled with 10 mm hole and 1 cut out
ACCESSORIES:
＊3010-02：2 asbestos gasket for each piece
＊3010-02-6：4 asbestos gasket for each piece
| PACKING INFORMATION |
| BOX | CARTON | N.W.(kgs) | G.W.(kgs) | Meas.(inches) |
| 8 | 80 | 27.00 | 28.00 | 18.5x7.25x9 |
Armstrong Glass Door Hinge 3010-02 – Brass Finish, 6mm/8mm Glass
- Material: High-quality brass for durability and elegance
- Glass Thickness Compatibility:
- 3010-02: For 8mm thick glass
- 3010-02-6: For 6mm thick glass
- Finish Options: Available in Chrome, Black, or Golden to match various interior styles
- Load Capacity: Supports up to 12 kg per pair
- Installation Requirements: Glass doors must be drilled with a 10mm hole and 1 cut-out
- Included Accessories:
- 2 asbestos gaskets per piece for 3010-02
- 4 asbestos gaskets per piece for 3010-02-6
- Packing Information: Packed 80 pairs per carton; Gross Weight: 28 kg
Discover the Armstrong Locks Cabinet Glass Door Hinge 3010-02, crafted from high-quality brass and available in Chrome, Black, or Golden finishes. Supports up to 12 kg per pair, suitable for 6mm or 8mm thick glass doors.
- Glass Showcases
- Jewelry Cabinets
- Home Interiors
- Office Spaces
- Exhibition Stands
