Cabinet Glass Door Hinge 3010-03
Cabinet glass door hinge 3010-03
Glass door hinge for showcase cabinets
Cabinet hardware for glass doors
Display case glass door hinge
Glass door hinge for showcase cabinets
Cabinet hardware for glass doors
Display case glass door hinge
модель :
3010-03
The Cabinet Glass Door Hinge 3010-03 is brass hinge engineered for 5–6 mm glass cabinet doors. Offering up to 3 kg load capacity per pair. Available in chrome, black, or golden finishes and designed for both glass and wood installations (drilled 19 mm hole required). Ideal for high-quality display showcases and glass cabinets.
The best quality with reasonable price glass cabinet hinge.
- 3010-03 FOR GLASS THINKNESS 5-6mm
- Color available for Chrome, Black or Golden
- CABINET GLASS DOOR HINGE –LOADING WEIGHT:3KGS
- Loading capability of brass is much better than zinc alloy as produced by other factories.
- Can be installed on glass or wooden board
- Glass need a hole for installation.
- Packing: 80prs/carton: G.W.:10KG
Cabinet Glass Door Hinge 3010-03 | Brass Hinge for 5-6 mm Glass Cabinet Doors
ITEM NO.: 3010-03 For glass thickness 5~6mm
Loading weight: 3kgs
| ORDER NO. | FINISH |
| C3010B-03 | CHROME |
| BK3010B-03 | BLACK |
- MATERIAL: Brass
-
ACCESSORIES: 2 washers for each piece
- UNIT: Pair
- Glass door must be drilled with 19 mm hole
| PACKING INFORMATION |
| BOX | CARTON | N.W.(kgs) | G.W.(kgs) | Meas.(inches) |
| 8 | 80 | 9.00 | 10.00 | 18.5x7.25x9 |
The Cabinet Glass Door Hinge 3010-03 — a durable brass hinge for 5–6 mm glass cabinet doors with a 3 kg load capacity. Available in chrome, black, or golden finishes, suitable for display cases and glass-wood installations.
- Designed for glass thickness 5–6 mm
- Made of brass (better loading performance vs. zinc alloys)
- Available finishes: Chrome, Black, Golden
- Load Capacity: supports up to 3 kg (loading weight)
- Installation : on glass (drilled hole required: 19 mm) or on wooden board
- Comes with 2 washers per hinge pair
- Supplied in pairs
- Carton packing: 80 pairs per carton; G.W. ~10 kg
- Glass showcase cabinets (retail displays, museum vitrines)
- Display cases in shops, galleries, or exhibition booths
- Glass-fronted cabinets in living rooms, kitchens, or offices
- Furniture with mixed glass and wood elements
- Replacement or retrofit of existing glass cabinet hinges
- Light-duty use where glass thickness is 5–6 mm
