Glass Door Hinge 3010-04
Armstrong glass door hinge 3010-04
Display cabinet glass door hinge
Showcase glass hinge 3010-04
No-bore-hole glass hinge cabinet
Furniture hardware glass door hinge
Display cabinet glass door hinge
Showcase glass hinge 3010-04
No-bore-hole glass hinge cabinet
Furniture hardware glass door hinge
модель :
3010-04
Armstrong Glass Door Hinge Model 3010-04 – hinge hardware for glass-front cabinets and showcases. Designed for high-load applications, minimal-drill installation and seamless integration with frameless or framed glass doors in retail, museum and commercial furniture environments.
Armstrong Glass Door Hinge Model 3010-04 | High-Load Display Cabinet Hardware
ITEM NO.: 3010-04 For glass thickness 5~6mm
Loading weight: 3kgs
| ORDER NO. | FINISH |
| C3010B-04 | CHROME |
| BK3010B-04 | BLACK |
- MATERIAL: Brass
- UNIT: Pair
- ACCESSORIES: 2 washers for each piece
- Glass door must be drilled with 19mm hole
| PACKING INFORMATION |
| BOX | CARTON | N.W.(kgs) | G.W.(kgs) | Meas.(inches) |
| 8 | 80 | 9.00 | 10.00 | 18.5x7.25x9 |
Discover the Armstrong 3010-04 glass door hinge — a high-performance, minimal-drill hinge designed for display cabinets and glass-door furniture. Ideal for retail, showroom and museum applications where durability and clean aesthetics matter.
- Retail display cabinets for jewellery, electronics or high-end merchandise where glass doors need reliable hinges.
- Museum or gallery glass-door display cases where minimal drilling is preferred to preserve aesthetic integrity.
- Furniture cabinets with glass fronts (in residential or commercial interiors) requiring glass-door hinge hardware.
- Shop-fitting fixtures, showroom installations and store-interior displays that demand clean hardware integration.
- Architectural glass cabinets or showcases in offices, hotels or hospitality spaces where appearance and durability matter.
