Cabinet Glass Door Hinge 3010-06-GG-180
180 degree glass to glass hinge
Glass cabinet 180 degree hinge
Glass-to-glass cabinet hinge 180°
Display brass hinge for 5–6 mm glass doors
Glass cabinet 180 degree hinge
Glass-to-glass cabinet hinge 180°
Display brass hinge for 5–6 mm glass doors
модель :
3010-06-GG-180
The Cabinet Glass Door Hinge 3010-06-GG-180 is a durable brass glass-to-glass hinge designed for 180° cabinet doors with 5–6 mm glass thickness. Available in chrome, black, and golden finishes, it’s ideal for display cases, showcases, and modern glass cabinets.
The reasonable price of hinge sell to over 80 countries.
3010-06M-GG-180 FOR GLASS THICKNESS 5-8mm
3010-06S-GG-180 FOR GLASS THICKNESS 4-6mm
- Material: Brass
- Finish: Chrome, Black or Golden
- CABINET GLASS DOOR HINGE –
- LOADING WEIGHT: SIZE (M):8KGS; SIZE (S):6KGS
- NON-BORE-HOLE SHOWCASE DISPLAY GLASS DOOR HINGE
- Open 180 degree
Packing: M:100prs/carton: G.W.:18.2KG
S:200pRs/carton: G.W.:17.2KG
Glass to Glass 180° Cabinet Door Hinge 3010-06-GG-180 | Brass Showcase Hinge
ITEM NO.:
- 3010-06M-GG-180 For glass thickness 5~8mm - Loading weight: 8kgs
- 3010-06S-GG-180 For glass thickness 4~6mm - Loading weight: 6kgs
| ORDER NO. | ORDER NO. | FINISH |
| C3010B-06M-GG-180 | C3010B-06S-GG-180 | CHROME |
| BK3010B-06M-GG-180 | BK3010B-06S-GG-180 | BLACK |
- MATERIAL: Brass
- UNIT: Pair
| PACKING INFORMATION |
| ITEM NO. | BOX | CARTON | N.W.(kgs) | G.W.(kgs) | Meas.(inches) |
| 3010-06M-GG-180 | 10 | 100 | 17.00 | 18.20 | 18.5x7.25x9 |
| 3010-06S-GG-180 | 20 | 200 | 26.00 | 27.20 | 18.5x7.25x9 |
Shop the 3010-06-GG-180 glass-to-glass cabinet hinge for 180° glass doors. Durable brass construction with chrome, black, and golden finishes. Perfect for display cabinets and showcases.
- Glass-to-glass hinge designed for 180° connections
- High-quality brass construction
- Finishes: Chrome, Black, Golden
- Suitable for 5–6 mm glass thickness
- Approx. 3 kg per hinge (consistent with other Armstrong hinges)
- Designed for glass-to-glass mounting
- Requires drilled hole (19 mm typical)
- Includes washers/hardware
- Glass display cabinets needing 180° glass-to-glass connections
- Retail showcases and jewelry cases
- Museum or exhibition
- Glass furniture and interior applications
- Frameless glass designs where no wood is used
